Alpine BBX-F1200

6.900,00 ден

Опис

General

  • Amplifier Type: Class-A/B
  • Channel Design: 4/3/2 Channel
  • Thermal Control: Thermal Management Control
  • Power Supply: DC-DC PWM Power Supply
  • Power Supply Design: MOSFET Power
  • Current Protection: Over-Current, Over-Voltage and Thermal Protection
  • Crossover: Variable Low-Pass / High-Pass
  • Green/red status LED
  • 2 pair RCA pre-inputs

SPECIFICATIONS

Max Power Output Ratings

  • Total Max Power: 600W

RMS Power Ratings

  • Per Channel into 4ohms (≤1%THD+N): 4 x 50W
  • Per Channel into 2ohms (≤1%THD+N): 4 x 70W
  • Bridged into 4ohms (≤1%THD+N): 2 x 130W

Sound Tuning

  • Crossover Frequency (Variable, OFF/LPF/HPF Selectable)
    1/2 Ch: LP/HP:  50Hz – 500Hz
    3/4 Ch: LP/HP:  50Hz – 500Hz
  • EQ (Equalizer): Bass EQ Fixed Frequency 45 Hz, Q=0.5, Variable Gain  0dB to +12dB (3/4 Ch only)

Dimensions

  • Footprint: 330 mm x 52 mm x 240 mm

General

  • Power Requirements: 14.4 V DC (11 V to 16 V)
  • Input Sensitivity: 0.2 – 8.0 V
  • Frequency Response: 5 Hz – 50 kHz (+ 0,-3 dB)
  • Speaker Impedance: 4 or 2 Ω
  • Signal to Noise: S/N Ratio (IHF A Weighted, Reference: rated power into 4ohms) 95 dB
  • Weight: 2.7 Kg

Brand

ALPINE Electronics

Алпине електроникс - Јапонија Водечка фирма во светот на висококвалитетна аудио опрема за автомобили, кампери камиони.
