Brand
Audio Technica
AUDIO TECHNICA AT-XP7DJ Cartridge
12.500,00 ден
Dual Moving Magnet Stereo Cartridge
The AT-XP7 is specially designed for the needs of DJs. This cartridge features a highly-rigid polyphenylene sulfide (PPS)/glass fiber body and a tracking force of 2 to 4 grams. It also offers a powerful output level of 6.0 mV, and its 0.3 x 0.7 mil elliptical bonded stylus tracks the record groove with high accuracy for outstanding audio reproduction. Plus, the cartridge is specifically designed to provide maximum visibility of the stylus tip.
- Durable robust design for high-quality specialist DJ playback
- Cartridges designed for DJ venue applications for their Hi Fi audio Performance
- Great visibility of stylus tip for instant positioning in dark environments
- Audiophile experience associated with DJ’ing environment with the signal output level and output impedance characteristics adapted to DJ professional mixing boards
- VM dual magnet cartridge with 0.3 x 0.7 mil elliptical bonded stylus
- Tapered aluminium cantilever
- Stainless wire suspension enables expressive higher frequency for clearer sound
- High-rigidity and Low-resonance cartridge housing
| Type | VM Dual Magnet |
| Mounting | Half-inch |
| Frequency Response | 20 – 20,000 Hz |
| Channel Separation | 22 dB at 1kHz |
| Output Channel Balance | Output Channel Balance |
| Output Voltage | 6.0 mV (mV at 1 kHz, 5 cm/sec) |
| Vertical Tracking Angle | 20° |
| Vertical Tracking Force Range | 2.0 – 4.0g |
| Stylus Shape | Elliptical |
| Stylus Size | 0.3 x 0.7 mil |
| Stylus Construction | Bonded Round Shank |
| Cantilever | Aluminium tapered Pipe |
| Coil Inductance | 1.0 H (1 kHz) |
| Static Compliance | 20 x 10-6 cm/dyne |
| Dynamic Compliance | 8.0×10-6cm/dyne (100Hz) |
| Recommended Load Impedance | 47,000 ohms |
| Recommended Load Capacitance | 100-200 pF |
| Weight | 6.2g |
| Dimensions | H17.2×W17.8×D28.3mm |
